2023  TYM Tractors  T574C - 55.1HP

Take on tough jobs in tight spaces with the T574. This tractor brings you the best features from our compact and utility ranges, balancing high power output with maximized maneuverability.

LOADER SPECIFICATIONS:

• Model: TX57
• Lift Height: 109.4"
• Max. lift height under level bucket: 101.0"
• Clearance with bucket dumped: 83.6"
• Reach at maximum lift height: 17.6"
• Max. dump angle: 50 degrees
• Reach with bucket on ground: 71.5"
• Max. rollback angle: 35 degrees
• Digging depth: 5.5"
• Lift capacity: 2,790 lb
• Breakout force at ground level, pivot points: 5,316 lb
• Bucket rollback force at ground line: 4,356 lb
• Bucket capacity: 11.3 cu. ft.
• Relief valve setting (Loader control valve): 2,489 psi
• Loader weight: 1,120 lb

INDUSTRIAL TIRE SPECIFICATIONS:

• Front R4: 12x16.50NHS 6PR
• Rear R4: 16.9-24 8PR
• Tire Weight: 798 lbs.

ENGINE:

• TYM A2300T3
• Turbocharged 4-Cylinder Diesel
• 55hp @ 2600 RPM
• PTO: 44.7HP

POWER STEERING:

• Power Steering w/ Dual-Gear Pump
• Wet Disc Brakes
• Selectable Four Wheel Drive
• Category I Three Point Hitch, 3,314 lbs Capacity
• 540 RPM Independent PTO
• 17 Gallon Fuel Capacity
• 70A Alternator, 12V System

WEIGHTS:

• Tractor: 4,233lbs
• Loader: 1,120lbs
• Total Weight: 5,353lbs
• Liquid Ballast (optional): 1,342lbs
• Total Weight with Ballast: 6,695lbs

WARRANTY INFORMATION:
Personal Use: 6-year warranty- The first two years is bumper to bumper on the tractor up to 2000 hours, whichever comes first. Loaders, backhoes and mowers have a 1 year limited warranty. The next 4 years will cover drivetrain parts and labor up to the 3000 hour mark.

Commercial Use: 3-year warranty- The first two years is bumper to bumper on the tractor up to 2000 hours, whichever comes first. Loaders, backhoes and mowers have a 1 year limited warranty. Year 3 will cover drivetrain parts and labor up to the 3000 hour mark.
